Tuesday, October 4, 2016

Miscellaneous

Ignition
Team Rush Link
Under Hood Light
  • GM 1599293
  • Fan: Napa BK 6551039
  • Spring: Ace #102
  • Foam: McMaster #86225K53 1/4" w/adhesive (24" square)
  • Foam: McMaster #86225K57 1" w/adhesive (24" square)
  • Foam: McMaster: #8865K51 1/2" w/adhesive (12" square)
  • Foam: McMaster: #8865K53 1" w/adhesive (12" square)
Hole: 3 1/2" (maybe 3 3/4")

Removal: Open glove box door, remove inside box insert. Unplug fan resistor wires, disconnect control cables from door levers (only the ones that come in from the dash). Remove the defroster duct flexible hose from the top of the box. Go under the hood. Disconnect the wire from the blower motor, heater hoses. Remove the nuts from the studs that hold the box to the firewall, don't forget the one behind the valve cover. Go inside the Jeep, pull the box back and may have to tilt it down in the rear a little to clear the firewall. I had mine out in about 15 minutes.

When I reinstalled mine, I put a self-tapping screw into the motor mounting flange with a ground wire attached to it. This way I knew the Blazer motor had a good clean ground.

Heater Core: Autozone Transpro #846071 - 399210 (make sure it has the silver L-bracket welded onto the hose side)


Drive Shaft
Steering
Brakes
Speed Bleeders
  • CJ 81-89
  • SB3824 Front Disk
  • SB1428 Rear Drum
Storage

Headlights

Thursday, July 28, 2016

Seats

Seats

  • Make: Bestop
  • Model: Trailmax II
  • Passenger  3945037
  • Driver  3945137
  • Vinyl
  • Color: Spice


  • Make: Bestop
  • Model: Trailmax II
  • Passenger  3946037
  • Driver  3946137
  • Fabric/Vinyl
  • Color: Spice


Thursday, June 30, 2016

Top - Doors

Top

Doors
  • Make: Bestop
  • Model: 5303801
  • Color: Black Crush
Roll Bar Cover
  • Make: Bestop
  • Model: 8000701
  • Color: Black Crush




Bumpers

Bumpers

Sunday, June 19, 2016

Lift - Wheels - Tires

Lift
  • None
Axles
Shocks
Wheels
  • Make: American Racing
  • Style: AR1725885B
  • Size 15 x 8
  • Bolt Pattern 5 on 5.5
  • Backspace: 3.75"
  • Offset: -19mm
  • Bore: 4.25"
  • Alloy
  • Satin Black


Tires
  • Make: Kuhmo
  • Model: Road Venture AT51
  • Size: 31 x 10.50 R 109R


Center Caps
  • Make: Topline
  • Model: C102S
  • Color: Polished Stainless
  • Size: 4.25"
  • Make: Topline
  • Model: C104S
  • Color: Polished Stainless
  • Size: 4.25"

Lug Set
  • Make: DPAccessories
  • Model: LCS3A2HC2CH04024
  • Color: Chrome
  • Size: 1/2"-20 Conical (24 each)
  • Height: 1.35"
  • Spline: 6/Tuner
  • Key: 3/4" (OEM) and 13/16"



Color Scheme

NEW PLAN

We had originally picked a burnt orange pearl, but Adam convinced us to go with more of a traditional Jeep color.  These photos are of another project that he did.  Every time I went over there, I must confess, I drooled over it.  Anyway, Mary and I are loving the new choice and look forward to watching the transformation!

Inspiration Photo

Inspiration Photo

Exterior
  • Body/Grille
    • Honda Carbon Bronze
    • Brand Code: 913624
    • DEM Code: YR562P-A, YR562P-G
    • Mixing Scheme: OMNI AU (MBC)
  • Trim: (hinges, cage, wipers, bezels, brackets, mirrors, etc.)
    • Duplicolor Low Gloss Black Engine Enamel #1634
  • Bumper/Running Board
    • Duplicolor Black Truck Bed Coating #TR50
  • Wheels
    • Satin Black
Interior
  • Tub Liner/Undercoat
    • Raptor
  • Engine Compartment
    • Raptor
  • Dash
    • Honda Carbon Bronze
Finally In The Spray Booth!






















Saturday, June 18, 2016

Progress Pics

October 2, 2016
Sold the top and doors to Adam for another client of his.

Work begins… colors decided.
Took the seats, dash, console, and fender flares home to work on them...




Sandblasted









Engine 258 - 4.2 - IL6


T5 Transmission


Seat Slider Cleaned

Heater Cables Painted

Seat Risers Painted


Primered
